1000ft 2C 22AWG Stranded Shielded Control Cable - CMR Riser - Black

( 0 Customer Reviews )

Model#: Cab-BK-CON428-BK

OEM Free shipping

$112.50

Color:

Quantity:

- +

Add To Wish List

In Stock: Order now to ship out in 1-2 business days

Earn 2250 S-Points Rewards

1-year warranty

Product Overview

Specifications

Customer Reviews

FAQ'S

Product Overview

This 2 conductor 22AWG stranded shielded control cable is black and white in color and 1000 feet in length. It is typically used in control panel and automation control applications.

Physical Characteristics
Cable Lengths Available	1000 foot [305m] Pull Box
Color (jacket)	Black/White
Number of Conductors	2 Conductors (Red/Black)
Jacket Material	PVC - Polyvinyl Chloride
Stranding	7*0.254mm
Min Average Jacket Thickness	0.38mm
Jacket Outer Diameter	4.6 0.15mm
Insulation Material	PVC - Polyvinyl Chloride
Insulation Outer Diameter	1.9mm
Min. Ave. Jacket Thickness	0.45 mm
Wire Gauge	22 AWG
Maximum Voltage	300V
Material (conductors)	Bare Copper
Ripcord	Yes
Shielding	Overall Foil Shielded 110%
Drain Wire	7*0.2mm Stranded Tinned Copper
Operating Temperature	-20C ~ +75C
Before Tensile Strength	>=13.8 Mpa
Aging Elongation	>=100%
Aging Condition	100x168oCxhrs
After Tensile Strength	>=85%Mpa of unaged
Aging Elongation	>=50% of unaged
Cold Bend	No Crack (-202o Cx4hrs)
Approvals
c(ETL)us	Compliant
Environmental
RoHS	Compliant
REACH	Compliant
Packaging Information
Package Quantity	1 Pull Box
Product Weight	22.53 lbs

1000ft 2C 22AWG Stranded Shielded Control Cable - CMR Riser
